2025 Merida Big Trail 300

Introduction

The same fun handling and trail taming performance as its bigger brothers, but in a wallet-friendly specification. This is affordable trail performance at its best.

Frame: BIG.TRAIL TFS II; MAT aluminium; 29×2.5″ max. WHS; 148×12 AST; BSA BBR
Fork: SR Suntour XCR34; Air; 140 STR; platform
Brake – Front: Shimano MT200; 2 piston
Brake – Rear: Shimano MT200; 2 piston
Rotor – Front: Shimano RT10; 180mm
Rotor – Rear: Shimano RT10; 180mm
Chain: KMC xGlide
Chainwheel: Shimano CUES U4000; 32 ATC
Crank/Size: 170 mm for all sizes
Bb Set: FSA BB-7420ST 127.5mm
Derailleur – Rear: Shimano CUES U4000;
Freewheel: Shimano LG300; 11-46 ATC; 9 GER
Grip: MERIDA COMP EC
H-Bar: MERIDA COMP TR; MAT aluminium; 780 WHB; 20 RHB
H-B Stem: MERIDA COMP TR; MAT aluminium; 35 DSH; +7′ ASD
H-Stem/Size: 40 mm
Hub – Front: Shimano TC500-B; 110×15 WHF; 32 SPH; Centerlock
Hub – Rear: Shimano TC500-HM-B; 148×12 WHR; 32 SPH; Centerlock
Axle – Rear: MERIDA COMP TR; including removeable lever, 6/4mm allen key
Rim: MERIDA COMP CC II; 25 IWR; MAT aluminium; tubeless ready
Saddle: MERIDA COMP SL; 25% recycled material; V-mount
Seat Clamp: MERIDA EXPERT
Seat Post: MERIDA COMP TR II; 34.9 DSP; 0 SSB; XS: 150 SPT?S: 170 SPT?M/L: 200 SPT?XL: 230 SPT
Shifter – Rear: Shimano CUES U4000
Tyre – Front: Kenda Regolith; 29×2.4″; wire
Tyre – Rear: Kenda Regolith; 29×2.4″; wire
