2025 Merida Big Nine 200

Introduction

Single chainring aluminium 29er hardtail, featuring a 100 mm air suspension fork, a 10-speed Shimano drivetrain and powerful hydraulic disc brakes. The BIG.NINE 200 is ready for your next off-road adventure.

Frame: BIG.NINE TFS IV; MAT aluminum; 29 WHS; 135×9 AST; BSA BBR; Smooth welding
Fork: Suntour XCR32-ATB LOR; Air; 100 STR; Lockout; 44mm fork offset
Brake – Front: Shimano MT200; 2 piston
Brake – Rear: Shimano MT200; 2 piston
Rotor – Front: Shimano RT10; 180mm
Rotor – Rear: Shimano RT10; 160mm
Chain: KMC xGlide
Chainwheel: Shimano CUES U6000; 32 ATC
Crank/Size: 170 mm-S, 175 mm-M up
Bb Set: Shimano MT500
Derailleur – Rear: Shimano CUES U6000; GS
Freewheel: Shimano LG300; 11-48 ATC; 10 GER
Pedal: VP VPE-891
Grip: MERIDA COMP EC
H-Bar: MERIDA EXPERT CC; MAT aluminium; 720 WHB; 10 RHB
H-B Stem: MERIDA COMP CC; MAT aluminium; 31.8 DSH; 7 ASD
H-Stem/Size: S:70 mm, M:80 mm, L:90 mm, XL:100 mm, XXL:110 mm
Hub – Front: Shimano QC300; 100×9 WHF; 32 SPH; Centerlock
Hub – Rear: Shimano QC300-HM; 135×9 WHR; 32 SPH; Centerlock
Rim: MERIDA COMP CC II; 25 IWR; MAT aluminium; tubeless ready
Saddle: MERIDA COMP SL; 25% recycled material; V-mount; incl. MERIDA minitool
Seat Clamp: MERIDA COMP QR
Seat Post: MERIDA COMP CC; MAT aluminium; 30.9 DSP; 0 SSB
Shifter – Rear: Shimano CUES U6000
Tyre – Front: Maxxis Rekon Race; 29×2.25″; wire
Tyre – Rear: Maxxis Rekon Race; 29×2.25″; wire
