2025 Kink Carve 16

Introduction

The Kink Carve 16 ensures riders of every age can not only find a bike that fits them but can also hold up to some real BMX riding. Kids are getting serious about BMX at younger and younger ages, and we love it. Properly proportioned geometry and components create a modern, yet comfortable ride, suited for the rider who isnt ready for the bump up to a larger 18 bike yet.

Frame: Kink Carve 100% Hi-Ten Steel
Fork: Kink Stryker 4130 Chromoly SteererTapered Fork Legs
Bars: Kink T700 7 100% Hi-Ten Steel
Grips: Mission Helix Mini
Stem: Mission Topload 40mm
Headset: Mission Sealed Integrated (41.8 x 45)
Brake Lever: Mission Mini
Brake Cable: Mission L1 Linear
Brakes: Mission CeaseV2
Cranks: Mission Triumph 3pc Tubular Chromoly 140mm 8 Spline
Bottom Bracket: Sealed Mid 19mm
Pegs: N/A
Pedals: Kink Hemlock
Chain: Mission 410
Sprocket: Mission Rank 25T
Seat: Mission Cypress Mini Combo
Seat Post: Mission Combo Steel Post
Seat Clamp: Mission Slim Clamp
Front Hub: Mission Covert Unsealed 3/8? Axle
Rear Hub: Mission Function Semi-Sealed Cassette 14mm
Driver: 9T
Rims: Mission X7
Tires: Mission Tracker 16×2.4″
Weight: 22lb 10oz
