2024 Merida Silex 7000

Introduction

Time to find out what’s over the horizon. Our carbon frame and fork deliver confident off-road handling with all-road ability thanks to a benchmark Shimano GRX 12-speed groupset and Easton EA70 AX wheels.

Frame: SILEX CF II; MAT carbon; 700x47C max.WHS; 100×12/142×12 AST; BSA BBR
Size: XS-S-M-L-XL
Fork: MERIDA SILEX II CF2; Tapered; MAT carbon; 700x47C max. WHS
Gears: 1 X 12
Chainwheel: Shimano GRX820; 42 ATC
Crank/Size: 170 mm-XS/S, 172,5 mm-M, 175 mm-L/XL
Bottom Bracket: Shimano SM-BBR60
Cassette: Shimano CS-M7100; 10-51 ATC; 12 GER
Chain: Shimano M7100
Derailleur – Rear: Shimano GRX822
Shifters: Shimano GRX820; 1x
Brakes: Shimano GRX820; Hydraulic disc
Rotor – Front: Shimano RT64; 180mm
Rotor – Rear: Shimano RT64; 180mm
Handlebar: MERIDA EXPERT GRII; MAT aluminium; 400mm (XS-S) , 420mm (M) , 440mm (L/XL)
Stem: MERIDA TEAM CC III; MAT aluminium; 31.8 DSH; -6 ASD
Stem/Size: 80 mm all sizes
Head Set: MERIDA-8158 Semi integrated HS
Seat Post: MERIDA EXPERT CC; 27.2 DSP; 15 SSB; Carbon
Saddle: MERIDA EXPERT SL; V-mount; incl. MERIDA minitool
Hub – Front: VP CLK170F; 100×12 WHF; 32 SPH; centerlock
Hub – Rear: VP CLK270R; 142×12 WHR; 32 SPH; centerlock
Axle – Front: MERIDA EXPERT TR
Axle – Rear: MERIDA EXPERT TR; including removable lever; 6/4mm allen key
Rims: Easton EA70 AX; 100×12 WHF; 142×12 WHR;24 IWR; 20 HRI; Centerlock; MAT aluminium
Tyres: Maxxis Rambler; 700x45C; fold; TR; EXO
Bottle Cage: Fidlock Integrated Base & MERIDA Bottle
Other: MERIDA Multitool with saddlebox
Other: Garmin Carrier + Garmin insert*2 + GoPro/Light Mount
Max Rider Weight: 120kg
