2022 Apollo Trail 10

Introduction

When its not about the destination, but the journey. That was the underlying design philosophy behind our trail bikes. Designed for aggressive trail riding, these bikes make sure you are grinning ear to ear for the entire ride.

Frame: 27.5″ lightweight trail specific alloy frame with integrated head tube, internal cable routing, replaceable derailleur hanger
Fork: RST Blaze 27.5 TnL, 120mm travel with hydraulic lockout and preload, alloy crown and lowers.
Rear Shock: N/A
Headset: A-head semi integrated 1-1/8″
Handlebar: Alloy low riser, W: 700mm, R: 15mm, bore: 31.8mm, sweep: 5
Grip: Lock-on grips, Kraton rubber
Headstem: Apollo 31.8mm 4 bolt stem, Ext: S/M/L=45mm
Crankset: Alloy MTB crank 28T L: S=170mm, M/L=175mm
Bottom Bracket: BSA threaded
Pedals: Low profile high impact resin
Front Derailleur: Nil
Rear Derailleur: SRAM X5
Shift Levers: SRAM X5 Trigger, 10 speed
Cassette: Sunrace CSMS3 10 speed cassette 11 – 42T
Chain: KMC X-10
Brakes: Tektro HD-M275 hydraulic disc brakes, F:180mm / R:160mm rotors
Wheels: 27.5″ Weinmann U-32 alloy 32 hole F/V double wall disc specific rims, alloy disc hubs and stainless spokes
Tyres: Veetire Flow Snap 27.5 x 2.35″ wire bead
Saddle: Apollo MTB sport saddle
Seatpost / Clamp: Alloy two bolt micro adjust, 27.2mm, L:350mm
Extras: N/A
Sizes: S, M, L
