2022 Apollo Scout 21X

Introduction

The frame and fork use familiar endurance road bike geometry paired with clearance for wider tyres, while carrier and fender mounts allow you to customise for any adventure. Shimanos gravel-specific groupsets provide quiet and stable gearing, and rugged reliability, allowing you to explore tracks you never thought possible.

Frame: Superlite butted 6061 alloy gravel road, integrated head tube and replaceable derailleur hanger
Fork: Full carbon straight blade flat mount disc fork with tapered 1-1/8 to 1-1/2″ carbon steerer, 12mm Thru Axle
Headset: A-head integrated 1-1/2 to 1-1/8″ bearings with 15mm cone spacer
Handlebar: Apollo butted alloy anatomic flared drop 31.8mm alloy W: M=44cm, L/XL=46cm
Grip: Soft PU wrap with gel
Headstem: Apollo 1-1/8″ 3D forged alloy 4 bolt stem. M/L=110mm, XL=120mm
Crankset: Shimano FC-RX600, GRX, 40T 2 piece crank, M=172.5mm, L/XL=175mm
Bottom Bracket: BSA Threaded
Pedals: Nil
Front Derailleur: Nil
Rear Derailleur: Shimano RD-RX812
Shift Levers: Shimano ST-RX600 11 speed shifters
Cassette: Shimano CS-M7000, 11-42T
Chain: KMC X-11
Brakes: Shimano ST-RX600 GRX hydraulic road disc brakes with 160mm rotors
Wheels: 700c Weinmann U-26 double wall disc specific rims, 32 hole 10 speed disc hubs with stainless spokes
Tyres: Veetire T-CX 700c x 40c, 27TPI, folding bead MPC – Multiple Purpose Compound
Saddle: Apollo road saddle
Seatpost / Clamp: Apollo alloy 27.2mm post, twin bolt with alloy seat clamp
Sizes: M, L, XL
